Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 38 of 65
T = t / ((IA/IT)-1)
2
T：Overcurrent delay (second)
t：Timing multiplier ratio
IA：Current max. load current（L1/L2/L3）
IT：Overcurrent setting value
Example：
t = 36
IA = 550A
IT =500A
Conclusion: T = 3600s(1hour)
8.2 ENABLE DEFINITION OF PROGRAMMABLE OUTPUT PORTS
Form 2
No.
Type
Description
0
Not Used
1
Custom Period 1
Details of function description please see the following.
2
Custom Period 2
3
Custom Period 3
4
Custom Period 4
5
Custom Period 5
6
Custom Period 6
7
Custom Combined 1
8
Custom Combined 2
9
Custom Combined 3
10
Custom Combined 4
11
Custom Combined 5
12
Custom Combined 6
13
Reserved
14
Reserved
15
Reserved
16
Reserved
17
Air Flap Control
Action when over speed shutdown and emergence stop. It
also can close the air inflow to stop the engine as soon as
possible.
18
Audible Alarm
Action when warning, shutdown, trips. Can be connected
annunciator externally. When “alarm mute” configurable
input port is active, it can remove the alarm.
19
Louver Control
Action when genset starting and disconnect when genset
stopped completely.
20
Fuel Pump Control
It is controlled by fuel pump of level sensor’s limited
threshold.
21
Heater Control
It is controlled by heating of temperature sensor’s limited
threshold.
22
Cooler Control
It is controlled by cooler of temperature sensor’s limited
