Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 40 of 65
57
Reserved
58
Reserved
59
Reserved
60
ECU Warning
Indicate ECU sends a warning signal.
61
ECU Shutdown
Indicate ECU sends a shutdown signal.
62
ECU Com Fail
Indicate controller not communicates with ECU.
63
PWM Voltage Raise
When output type of AVR set as “Relay output”, controller
adjust voltage and reactive power via “Sync Raise Volt”
and “Sync Drop Volt”
64
PWM Voltage Drop
65
PWM Speed Raise
When output type of GOV set as “Relay output”, controller
adjust speed and power via “Sync Raise Speed” and
“Sync Drop Speed”
66
PWM Speed Drop
67
Reserved
68
Reserved
69
Digital Input 1 Active
Action when input port 1 is active
70
Digital Input 2 Active
Action when input port 2 is active
71
Digital Input 3 Active
Action when input port 3 is active
72
Digital Input 4 Active
Action when input port 4 is active
73
Digital Input 5 Active
Action when input port 5 is active
74
Digital Input 6 Active
Action when input port 6 is active
75
Digital Input 7 Active
Action when input port 7 is active
76~98
Reserved
99
Emergency Stop
Action when emergency stop alarm.
100
Fail To Start
Action when failed start alarm.
101
Fail To Stop
Action when failed stop alarm.
102
Under Speed Warn
Action when under speed alarm.
103
Under Speed Shutdown
Action when under speed shuts down.
104
Over Speed Warn
Action when over speed warn.
105
Over Speed Shutdown
Action when over speed shutdown alarm.
106
Reserved
107
Reserved
108
Reserved
109
Gen Over Freq. Warn
Action when generator over frequency warning.
110
Gen over Freq. Shut
Action when generator over frequency shutdown alarm.
111
Gen Over Volt Warn
Action when generator over voltage warning.
112
Gen Over Volt Shut
Action when generator over voltage shutdown.
113
Gen Under Freq. Warn
Action when generator low frequency warning.
114
Gen Under Freq. Shut
Action when generator low frequency shutdown.
115
Gen Under Volt. Warn
Action when generator low voltage warning.
116
Gen Under Volt. Shut
Action when generator low voltage shutdown.
117
Gen Loss of Phase
Action when generator loss phase.
118
Gen Phase Sequence
Wrong
Action when generator reverse phase.
119
Reserved
120
Over Power
Action when controller detects generator have over
power.
121
Reserved
