HMC6 Power Management Controller User Manual Page 68 of 87
No.
Name
Description
Remark
16.
Input 1 Active
Active when input port 1 is active
17.
Input 2 Active
Active when input port 2 is active
18.
Input 3 Active
Active when input port 3 is active
19.
Input 4 Active
Active when input port 4 is active
20.
Input 5 Active
Active when input port 5 is active
21.
Input 6 Active
Active when input port 6 is active
22.
Input 7 Active
Active when input port 7 is active
23.
Input 8 Active
Active when input port 8 is active
24.
Input 9 Active
Active when input port 9 is active
25.
Reserved
Reserved
26.
Gen Over Frequency 1
Active when the generator over frequency 1 alarm
occurs.
27.
Gen Over Frequency 2
Active when the generator over frequency 2 alarm
occurs.
28.
Gen Over Frequency 3
Active when the generator over frequency 3 alarm
occurs.
29.
Gen Over Voltage 1
Active when the generator over voltage 1 alarm
occurs.
30.
Gen Over Voltage 2
Active when the generator over voltage 2 alarm
occurs.
31.
Gen Under Frequency 1
Active when the generator under frequency 1 alarm
occurs.
32.
Gen Under Frequency 2
Active when the generator under frequency 2 alarm
occurs.
33.
Gen Under Frequency 3
Active when the generator under frequency 3 alarm
occurs.
34.
Gen Under Voltage 1
Active when the generator under voltage 1 alarm
occurs.
35.
Gen Under Voltage 2
Active when the generator under voltage 2 alarm
occurs.
36.
Gen Under Voltage 3
Active when the generator under voltage 3 alarm
occurs.
37.
Gen Loss of Phase
Action when generator loss phase.
38.
Gen Phase Sequence Wrong
Action when generator reverse phase.
39.
Busbar Over Frequency 1
Active when the busbar over frequency 1 alarm
occurs.
40.
Busbar Over Frequency 2
Active when the busbar over frequency 2 alarm
occurs.
41.
Busbar Over Frequency 3
Active when the busbar over frequency 3 alarm
occurs.
42.
Busbar Under Frequency 1
Active when the Busbar under frequency 1 alarm
occurs.
