harness during the disassembly process to avoid the risk of electric shock.
8) When repairing or replacing high-voltage wiring harnesses, oil pipes, and other parts that pass
through the holes in the body sheet metal, take care to check whether the protection with the
body sheet metal is normal to avoid wear and tear of the wiring harnesses and oil pipes.
The following agreement is used in the Manual.
Tips
Tips provide helpful information such as additional operating instructions, skills and advice.
Example:
Tip: The VIN number is usually located on the driver's side, in the lower right corner of the
front windscreen. The exact location varies from vehicle to vehicle. The VIN number consists of 17
standardized characters. The VIN characters can contain capital letters A to Z and numbers 0 to 9,
but the letters I, O and Q are not normally used to avoid misreading.
Warning
Indicates an emergency dangerous situation which, if unavoidable, will result in death or serious
injury to the operator or onlookers. Example:
Warning: Reading fault codes when troubleshooting a vehicle is only a small step in the
overall diagnostic process. Vehicle fault codes are provided as a reference only and parts cannot
be replaced directly based on the fault code definitions given. Each fault code has a test procedure,
and the service technician must strictly follow the operating instructions and procedures described
in the vehicle service manual to identify the root of the malfunction.
Danger
Indicates an emergency dangerous situation which, if unavoidable, will result in death or serious
injury to the operator or onlookers. Example:
Danger: You must drive the vehicle when performing the vehicle troubleshooting, please get
someone else to help you. Driving and operating the diagnostic device at the same time is
dangerous and can cause serious traffic accidents.
