Smarty Saver Plus - Page 28

SEMI-AUTOMATIC
28
The table below shows the main operations to be performed during CPR and the related visual/voice/text commands
provided by SMARTY Saver Plus.
No.
Type of command
SMARTY Saver Plus instructions
Operations to be performed
1
Voice
“Start
Cardio-Pulmonary Resuscitation”
A. Check that the patient is on a firm surface
B. Kneel at the victim’s side
C. Place the heel of one hand on the centre of the victim’s chest
D. Place the heel of the other hand on top of the first
E. Link the fingers of the two hands and make sure that the pressure is
not applied to the ribs. Do not apply any pressure on the upper part of
the abdomen or on the lower part of the sternum.
Visual
ILLUMINATED ICON
2
Voice
“Quickly press on the patient’s chest”
F. Place yourself vertically to the victim’s chest and, with arms
extended, press the sternum. Keeping the arms extended, perform
external cardiac massage by using the weight of the torso; the
oscillating movement must be centred around the hip joint.
G. After each compression, release all pressure on the chest without
losing contact between your hands and the sternum; repeat the
manoeuvre with a frequency of 100/min (a little fewer than 2
compressions per second)
H. The compression/release phases must be of equal duration.
Visual
ILLUMINATED ICON
Acoustic Signal
(BEEP)
a BEEP marks each compression to be
performed.
3
Voice
“Perform two insufflations”
“Blow”
“Blow”
Open immediately the air passage by tilting the head and the chin
backwards
Perform two insufflations
The rescuer breathes normally and, keeping the chin up with two
fingers, puts their lips around the patient’s mouth. The opposite hand
closes the nostrils to keep the air from coming out and keeps the head
hyper-extended. Air is blown in breathing normally for about 1 second
Visual
ILLUMINATED ICON
steps 1 to 3 will be repeated for approximately 2 minutes
Follow the voice and text instructions of SMARTY Saver Plus until
the device completes the CPR phase (approximately 2 minutes).
