Smarty Saver Plus - Technical Specifications; Physical, Environmental, and Regulatory

SEMI-AUTOMATIC
34
10 Technical specifications
Below please find the technical specifications of the SMARTY Saver Plus defibrillator, its parts and accessories.
10.1 Physical characteristics
Category
Rated specifications
Dimensions
200 x 213 x 71 mm (handle folded)
257.x 213 x 71 mm (handle extended)
Weight
1.62 Kg (including Pads and battery)
10.2 Environmental requirements
Category
Rated specifications
Temperature
Operational and
stand-by:
0°C to 45°C (32°F to 113°F)
Storage and
transport:
-40°C to 70°C (-40°F to 158°F)
Relative humidity
Operational and
stand-by:
10% to 95% (without condensation)
Storage
and transport:
- without humidity control: from -40°C to +5°C
- up to 90% humidity: from +5°C to +35°C
- with water vapour up to 50hPa: from >35°C to +70°C
Atmospheric pressure
Operating conditions:
620hPa to 1060 hPa
(calculated altitude min -382 and max 3,955 mt)
Operating conditions
Normal use:
Keep the AED device within the operating and stand-by range (10%
to 95% without condensation), so that the device is ready for use.
Instead, after storage
and transport conditions, let the device stabilise for at least 2 hours
at operating conditions, before normal use.
Tolerance to shocks and falls
In compliance with standards IEC/EN 60601-1 clause 21 (mechanical forces)
Sealing system
In compliance with standards IEN/EN 60529 class IP56;
splash-proof, dust-proof (with the battery installed)
ESD (electrostatic discharge)
In compliance with the standards IEC/EN 61000-4 2
EMC emissions/immunity
Please see paragraph 11
10.3 Reference regulatory frameworks
Regulatory frameworks and
Directives
DIRECTIVE 2007/47/EC
EN 60601-1
EN 60601-1-2
EN60601-1-4
EN60601-1-6
EN60601-1-8
IEC 60601-1-11
IEC 60601-1-12
EN 60601-2-4
IEC 60086-4
EN 60529
DIRECTIVE 2014/53/EU - RED
