E1: Planning
Checklist for planning the use of the module
Device type/equipment identification
Version: HW/FW
Date
Test engineer 1
Test engineer 2
Remark
No.
Requirement (mandatory)
Yes
Remark
1
Has the current module user manual been used as the basis for
planning?
Revision:
2
Are the actuators approved for connection to the module
(according to the technical data and parameterization options?)
3
Has the voltage supply been planned according to the
specifications for the protective extra-low voltage in according
with PELV?
4
Has the power supply of US1 and US2 from a power supply
unit been planned?
5
Is external protection of the module planned (according to the
specifications in this user manual for supply voltage US1 and
US2)
6
Are measures planned to prevent simple manipulation of US1
and US2?
7
Are measures planned to prevent connectors being mixed up?
8
Are requirements for the actuators and cable installation
observed according to the SIL/SILCL/Cat./PL to be achieved
and is the corresponding implementation planned?
9
Are the specifications for the parameterization for each channel
specified?
10
Are test intervals specified for testing the shutdown capability of
the actuators, if this is required to achieve a
SIL/SILCL/Cat./PL?
11
Has it been ensured that any person intentionally starting
hazardous movements can only do so with a direct view of the
danger zone?
12
Does the planned use correspond to the intended use?
13
Are the ambient conditions as well as the maximum mechanical
load observed according to the technical data?
14
Have test intervals been defined and has the maximum
duration of use been taken into consideration?
15
Has the switch-off delay for stop category 1 been observed in
the calculation of the total response time fir the
machine/system?
No.
Requirement (optional)
Yes
No
Remark
16
Have specifications for assembly and electrical installation been
defined (e.g., EPLAN) and communicated to the relevant
personnel?
17
Have specifications for startup been defined and communicated
to the relevant personnel?
Date
Signature (editor)
Date
Signature (test engineer)
