SMC Networks EX245-FPS1 User Manual

- 76 -
No.EX##-OMY0004
12.2. Specifications
Table 12-1 EX245-DY1 specifications
Item
Description
General
Dimensions (W x L x H) in mm
54 x 120 x 61
Weight
280 g or less
Housing material
Nylon, PBT
Electrical
Rated supply voltage
24 V DC
Voltage drop to load supply
Max. 1.6 V
Internal current consumption at 24 V DC
50 mA or less
Load connection
4 x M12, 5-way sockets with double allocation
Over Voltage protection
Yes, more than 30 V DC at US2(solenoid/output)
Short circuit protection
Yes
Output current per output
Max.0.5A
Output current per module
Max.2 A
Status indication
Yes, per output
Short circuit indication
Yes, per output
Digital output
Number of outputs
8
Output type
PNP
