11.2. Specifications
Table 11-1 EX245-DX1 specifications
Item
Description
General
Dimensions (W x L x H) in mm
54 x 120 x 61
Weight
280g or less
Housing material
Nylon, PBT
Electrical
Rated supply voltage
24 V DC
Voltage drop to sensor supply
Max. 1.6 V
Internal current consumption at 24V DC
50 mA or less
Input connection type
8 x M12, 5-way sockets with double allocation
Over Voltage protection
Yes,more than 30 V DC at US1(solenoid/output)
Short circuit protection
Yes
Sensor supply current per connector
Max. 0.5A
Sensor supply current per module
Max. 2 A
Status indication
Yes, per input
Short circuit indication
Yes, per connector
Digital input
Number of inputs
16
Input type
PNP
Signal 1
11 to 30 V
Signal 0
-3 to 5 V
Permissible residual current
Max. 1.5mA
Input current signal 1
Typ. 4.5 mA
