SMC Networks EX245-FPS1 User Manual

- 45 -
No.EX##-OMY0004
9.1.1.2. General diagnostics 2
Table 9-3 General diagnostics 2
Bit
Description
Explanation
0
Module 1 error
0: No error or not connected, 1: Module 1 has an error
1
Module 2 error
0: No error or not connected, 1: Module 2 has an error
2
Module 3 error
0: No error or not connected, 1: Module 3 has an error
3
Module 4 error
0: No error or not connected, 1: Module 4 has an error
4
Module 5 error
0: No error or not connected, 1: Module 5 has an error
5
Module 6 error
0: No error or not connected, 1: Module 6 has an error
6
Module 7 error
0: No error or not connected, 1: Module 7 has an error
7
Module 8 error
0: No error or not connected, 1: Module 8 has an error
9.1.1.3. Valve diagnostics 1
Table 9-4 Valve diagnostics 1
Bit
Description
Explanation
0
Valve Zone 1, coil 1 diagnostic
0: No error, 1: Fault

1
Valve Zone 1, coil 2 diagnostic
0: No error, 1: Fault

2
Valve Zone 1, coil 3 diagnostic
0: No error, 1: Fault

3
Valve Zone 1, coil 4 diagnostic
0: No error, 1: Fault

4
Valve Zone 1, coil 5 diagnostic
0: No error, 1: Fault

5
Valve Zone 1, coil 6 diagnostic
0: No error, 1: Fault

6
Valve Zone 1, coil 7 diagnostic
0: No error, 1: Fault

7
Valve Zone 1, coil 8 diagnostic
0: No error, 1: Fault

: Fault – short circuit
9.1.1.4. Valve diagnostics 2
Table 9-5 Valve diagnostics 2
Bit
Description
Explanation
0
Valve Zone 2, coil 1 diagnostic
0: No error, 1: Fault

1
Valve Zone 2, coil 2 diagnostic
0: No error, 1: Fault

2
Valve Zone 2, coil 3 diagnostic
0: No error, 1: Fault

3
Valve Zone 2, coil 4 diagnostic
0: No error, 1: Fault

4
Valve Zone 2, coil 5 diagnostic
0: No error, 1: Fault

5
Valve Zone 2, coil 6 diagnostic
0: No error, 1: Fault

6
Valve Zone 2, coil 7 diagnostic
0: No error, 1: Fault

7
Valve Zone 2, coil 8 diagnostic
0: No error, 1: Fault

: Fault – short circuit
