- 60 -
No.EX##-OMY0004
Byte 1: Status of the status bit in Byte 0
This indicates if Byte 0 status bits are valid or not
Table 10-17 Byte 1 Status of the status bit in Byte 0
Bit
Description
Explanation
0
Status of status bit for safe output for IO Module
0: invalid, 1: valid
1
Status of status bit for safe output for valve zone 1
0: invalid, 1: valid
2
Status of status bit for safe output for valve zone 2
0: invalid, 1: valid
3
Status of status bit for safe output for valve zone 3
0: invalid, 1: valid
4…7
Reserved
Fixed 0
Byte 2: Switch ON ready
This indicates if the safe output can turn ON without error due to the output feedback function (see 8.2.2.5 for
details).
Table 10-18 Byte 2 Switch ON ready
Bit
Description
Explanation
0
Switch on ready for output for IO Module
0: cannot turn on, 1: can turn on
1
Switch on ready for output for valve zone 1
0: cannot turn on, 1: can turn on
2
Switch on ready for output for valve zone 2
0: cannot turn on, 1: can turn on
3
Switch on ready for output for valve zone 3
0: cannot turn on, 1: can turn on
4…7
Reserved
Fixed 0
