SMC Networks EXW1-BMJA Series User Manual

-68-
No.EX※※-OMZ0016
Problem No.
LED
Name
LED status
Possible causes
Investigation and
countermeasures
Colour
of LED
ON/Flashing
4 W-SS
Red Flashing
When Protocol V.1.0 is used
(1) Power supply for the Base is
OFF
(2) Outside the wireless coverage
area
(1) Supply 24 VDC +/-10% for the
US1 (for control) power source
of the Base.
(2) The distance which wireless
communication between
wireless systems can be
established may have been
exceeded.
Reconsider the operating
environment, such as the
installation conditions, of the
Base and Remote.
Orange Flashing
When Protocol V.2.0 is used
(1) Power supply for the Base is
OFF
(2) Outside the wireless coverage
area
(1) Supply 24 VDC +/-10% for the
US1 (for control) power
source of the Base.
(2) The distance which wireless
communication between
wireless systems can be
established may have been
exceeded.
Reconsider the operating
environment, such as the
installation conditions, of the
Base and Remote.
- OFF
(1) Remote not registered
(2) The US1 (for control / input)
power supply is OFF
(1) Check the registration status of
the Remote and perform
pairing correctly.
(2) Supply 24 VDC +/-10% for US1
(for control / input) power
source.
