SMC Networks EXW1-BMJA Series User Manual

-69-
No.EX※※-OMZ0016
Problem No.
LED
Name
LED status
Possible causes
Investigation and
countermeasures
Colour
of LED
ON/Flashing
5 W-NS
Red Flashing
(1) Power supply for the Base is
OFF
(2) Outside the wireless coverage
area
(1) Supply 24 VDC +/-10% for the
US1 (for control) power source
of the Base.
(2) The distance which wireless
communication between
wireless systems can be
established may have been
exceeded.
Reconsider the operating
environment, such as the
installation conditions, of the
Base and Remote.
Red ON Remote malfunction
Replace the Remote
If the error persists after
replacement, stop using the
equipment and contact your SMC
sales representative.
Re
d
Gr
ee
n
Alternate
Flashing
In pairing mode.
The system has been set to
"Pairing enable". Change the
setting to "Pairing disable" when
pairing is not conducted.
Orange Flashing (1 Hz) Fn (pairing button) in use
Fn is being used. Change the
mode according to the
application.
- OFF
(1) Base not registered
(2) The US1 (for control / input)
power supply is OFF
(1) Check the registration status of
the Remote and perform
pairing correctly.
(2) Supply 24 VDC +/-10% for US1
(for control / input) power
source.
