SMC Networks EXW1-BMJA Series User Manual

-90-
No.EX※※-OMZ0016
Item
Resister
area
Bit
No.
Content of diagnostics
Diagnosed area and
processing upon error
How
to
reset
Reset conditions
Remarks
(LED indications,
etc.)
Item Details
Effective
diagnostic
coverage
I/O processing
upon
diagnosis
Remote
diagnostic
information
Wireless
channels
1-7
(Bit 0 is
for Base)
RWr4
0
Presence / absence of system
information error of Base
- - - -
No error in the
Base / Remote
when the
diagnostic
data is "0".
Error in the
Base / Remote
when the
diagnostic
data is "1".
1
Presence / absence of system
information
error of Remote (Wireless channel 1)
- - - -
2
Presence / absence of system
information
error of Remote (Wireless channel 2)
- - - -
3
Presence / absence of system
information
error of Remote (Wireless channel 3)
- - - -
4
Presence / absence of system
information
error of Remote (Wireless channel 4)
- - - -
5
Presence / absence of system
information
error of Remote (Wireless channel 5)
- - - -
6
Presence / absence of system
information
error of Remote (Wireless channel 6)
- - - -
7
Presence / absence of system
information
error of Remote (Wireless channel 7)
- - - -
Remote
diagnostic
information
Wireless
channels
8-15
8
Presence / absence of system
information
error of Remote (Wireless channel 8)
- - - -
9
Presence / absence of system
information
error of Remote (Wireless channel 9)
- - - -
10
Presence / absence of system
information
error of Remote (Wireless channel 10)
- - - -
11
Presence / absence of system
information
error of Remote (Wireless channel 11)
- - - -
12
Presence / absence of system
information
error of Remote (Wireless channel 12)
- - - -
13
Presence / absence of system
information
error of Remote (Wireless channel 13)
- - - -
14
Presence / absence of system
information
error of Remote (Wireless channel 14)
- - - -
15
Presence / absence of system
information
error of Remote (Wireless channel 15)
- - - -
