No.EX※※-OMZ0016
Item
Resister
area
Bit
No.
Content of diagnostics
Diagnosed area and
processing upon error
How
to
reset
Reset conditions
Remarks
(LED indications,
etc.)
Item Details
Effective
I/O processing
upon
Remote
information
Wireless
channels
1-7
(Bit 0 is
fixed at
"0".)
RWr5
0 - - - - -
When the
registration
data is "0", no
Remote has
been registered.
When the
registration
data is "1",
a Remote has
been registered.
1
Registration of Remote
(Wireless channel 1)
- - - -
2
Registration of Remote
(Wireless channel 2)
- - - -
3
Registration of Remote
(Wireless channel 3)
- - - -
4
Registration of Remote
(Wireless channel 4)
- - - -
5
Registration of Remote
(Wireless channel 5)
- - - -
6
Registration of Remote
(Wireless channel 6)
- - - -
7
Registration of Remote
(Wireless channel 7)
- - - -
Remote
information
Wireless
channels
8-15
8
Registration of Remote
(Wireless channel 8)
- - - -
9
Registration of Remote
(Wireless channel 9)
- - - -
10
Registration of Remote
(Wireless channel 10)
- - - -
11
Registration of Remote
(Wireless channel 11)
- - - -
12
Registration of Remote
(Wireless channel 12)
- - - -
13
Registration of Remote
(Wireless channel 13)
- - - -
14
Registration of Remote
(Wireless channel 14)
- - - -
15
Registration of Remote
(Wireless channel 15)
- - - -
*1: The LED indicator W-MS indicates the system status of the Remote.
If it is ON or flashes, errors have occurred in the registered Remote.
*: When the diagnostic data of the system diagnostics 1-4 is "0", no error has occurred. When it is "1", errors have occurred.
*: This table is for when the number of registered Remotes is set to 15 in the Base settings.
The diagnostic sizes of Remote connection information, diagnostic information and registration information vary depending on the
setting for the number of registered wireless units.
To Next Page
