Chapter 5 Display and Setting of Various Functions
HRSH Series 5.22 Alarm Customizing Function
5-51
Table 5.22-2 Default alarm settings and customizing (2/4)
Code
Alarm name
1. Operation during alarm
generation
2. Threshold for alarm generation and
other settings
4
Display
A.STP
A.RUN
P.RUN
OFF
Display
Default
Settable range
AL04
Circulating fluid
discharge temp.
drop
●
○
-
●
Set temperature
1.0
o
C
(33.8
o
F)
(----)
5
1.0 to 34.0
o
C
(33.8 to 93.2
o
F)
Monitoring method
0
0 to 3
Monitoring start timer
----（0）
6
0 to 600 minutes
Range over detection timer
5
5 to 999 seconds
AL05
High circulating
fluid return temp.
-
○
-
-
-
-
-
AL08
Circulating fluid
discharge pressure
rise
○
●
-
●
Set pressure (HRSH250/300-A,
HRSH100/150/200/250-W-T)
1.00 MPa
(145 PSI)
(----)
7
0.05 to 1.00 MPa
(7 to 145 PSI)
Set pressure (Other models)
0.70 MPa
(102 PSI)
(----)
7
0.03 to 0.70 MPa
(4 to 102 PSI)
AL09
Circulating fluid
discharge pressure
drop
○
●
-
●
Set pressure (HRSH250/300-A,
HRSH100/150/200/250-W-T)
0.05 MPa
(7 PSI)
(----)
8
0.05 to 1.00 MPa
(7 to 145 PSI)
Set pressure (Other models)
0.03 MPa
(4 PSI)
(----)
8
0.03 to 0.70 MPa
(4 to 102 PSI)
AL10
High compressor
intake temp.
●
-
○
-
-
-
AL11
Low compressor
intake temp.
●
-
○
-
-
-
AL12
Low super heat
temp.
●
-
○
-
-
-
AL13
High compressor
discharge pressure
●
-
○
-
-
-
AL15
Refrigerant circuit
pressure (high
pressure side) drop
●
-
○
-
-
-
4: Values are shown in
o
F when the unit is set to F for SE12, and in PSI when the unit is set to PSI for SE13.
5: Default value when AS05 is set OFF.
6: Default value when AS21 is set to either 2 or 3.
7: Default value when AS07 is set OFF.
8: Default value when AS09 is set OFF.
