Chapter 6 Alarm Notification and Troubleshooting
HRSH Series 6.3 Troubleshooting
6-7
Table 6-3 Alarm codes troubleshooting (3/3)
Code
Alarm name
Alarm
operation
*1
(Default)
Cause / Remedy
(Press the reset key after eliminating the
cause.)
AL40
2
Dust-proof filter
maintenance
OFF
Notice of the periodical
maintenance.
Clean the dust-proof filter.
Reset the operation cumulated
time for the alarm with the
menu after cleaning
the filter. This alarm can be
OFF with the menu .
1 to 9999
hours
(AS.31)
AL41
Power stoppage
A.STP
Power supply has been stopped during the
product operation.
Restart the power supply after checking.
AL42
Compressor standby
A.RUN
Waiting for the compressor to be ready for
operation. Wait for a while.
The alarm will be reset automatically after
starting operation.
AL43
2
Fan breaker trip
P.RUN
- Check that there
is no abnormality
with the power
supply system
(e.g. ground fault,
short-circuit,
voltage fluctuation,
abnormal
interphase voltage,
open phase,
surge).
Reset the fan breaker
trip with referring to
“6.3.2 How to release
the fan breaker trip”.
AL44
2
Fan inverter error
P.RUN
AL45
1
Compressor breaker
trip
P.RUN
- Press the [▼] and [▲]
keys on the operation panel
together at the same time
for 10 seconds to reset the
alarm. (After resetting
AL48, “WAIT”
will be displayed and the
product cannot start
operation for 40 seconds.
Restart 40 seconds later
after resetting.)
AL46
Compressor inverter
error
P.RUN
AL47
1
Pump breaker trip
A.STP
AL48
Pump inverter error
A.STP
AL49
3
Air exhaust fan
stoppage
A.RUN
Air exhaust fan failure. Ask for service for the
air exhaust fan.
*1: Power supply "-20" specification model does not generate this alarm. (Except option S.)
*2: Water-cooled type model does not generate this alarm.
*3: Air-cooled type model does not generate this alarm.
