Chapter 5 Display and Setting of Various Functions
5.2 Function HRSH Series
5-6
Table 5.2-3 List of parameters (3/3)
Display
Content
Default
Reference
page
Category
Unused
----
5.22
Alarm setting
menu
Unused
----
Temperature alarm monitoring method
0
Operation setting for the monitoring start timer
---- (0)
*7
Threshold time setting for the range over detection timer
5
Alarm settings for the compressor
P.RUN
Operation setting when "Circulating fluid discharge
pressure sensor failure " alarm is generated
A.STP
Operation setting during maintenance of the pump
OFF
Operation setting during maintenance of the fan
OFF
Operation setting during maintenance of the compressor
OFF
Operation setting during maintenance of the dust-proof
filter
OFF
Operation setting at a time of operation restoration after
power failure
A.STP
Changing of the dust-proof filter maintenance time
----
Communication mode
LOC
5.23
Communication
setting menu
Serial communication
Serial protocol
MDBS
Communication specification
485
RS-485 terminating resistor
OFF
Mod
bus
Slave address
1 (----)
*8
Communication speed
19.2 (----)
*8
Simple
communication
protocols
Slave address
---- (1)
*8
Communication speed
---- (9.6)
*8
BCC
---- (ON)
*8
Data length
---- (8BIT)
*8
Parity check
---- (NON)
*8
Stop bit length
---- (2BIT)
*8
Response delay time
---- (0)
*8
Communication range
---- (RW)
*8
Contact input/output
communication
Contact input signal 1
RUN
Contact input signal 1 type
ALT
Contact input signal 1 delay timer (time delay) for
reading
---- (0)
*8
Contact input signal 1 OFF detection timer
---- (0)
*8
Contact input signal 2
OFF
Contact input signal 2 type
ALT
Contact input signal 2 delay timer (time delay) of
reading
---- (0)
*8
Contact input signal 2 OFF detection timer
---- (0)
*8
Contact output signal 1 function
RUN
Contact output signal 1 operation
A
Contact output signal 1 selected alarm
---- (AL.01)
*8
Contact output signal 2 function
RMT
Contact output signal 2 operation
A
Contact output signal 2 selected alarm
---- (AL.01)*
8
Contact output signal 3 function
ALM
Contact output signal 3 operation
B
Contact output signal 3 selected alarm
---- (AL.01)*
8
*7: For more details of the default settings, refer to “5.22 Alarm Customizing Function”.
*8: For more details of the default settings, refer to “5.23 Communication Function”.
