HRX-OM-Q026
Chapter 5 Display and Setting of Various Functions
5.7 Run Timer and Stop Timer Function HRSH Series
5-16
Timer setting examples
Run timer
Set to start 3 hours later
Stop timer
Set to stop 3 hours later
Run timer +
Stop timer
Set to start 2 hours later,
and stop 5.5 hours later
Stop timer +
Start timer
Set to stop 2 hours later,
and start 5.5 hours later
⚫ Set while the breaker is ON (while the power is supplied).
⚫ The setting is released when operation is started or stopped by the
timer. Setting is necessary again to use the timer next time as well.
⚫ Run timer setting is released when the breaker or the user’s power
supply facility is cut, or a power failure occurs. Please set it again.
To Next Page
