Chapter 4 Starting the Product
HRSH Series 4.5 Check Items during Startup
4-9
4.5 Check Items during Startup
Check the following items after starting the product.
● Confirm that there is leakage from the piping.
● Confirm that no circulating fluid is discharged from the tank drain port.
● Confirm that the circulating fluid pressure is within the specification
range.
● Confirm that the fluid level shown by the fluid level gauge is within the
specification range.
4.6 Adjustment of Circulating Fluid Flow Rate
When the circulating fluid flow rate is smaller than the minimum required,
the product may fail to maintain the performance, making it impossible for
the compressor to operate.
Refer to "Fig. 3-18 Recommended piping circuit", and adjust the flow rate
with the manual valve to the required pressure or flow rate while monitoring
the pressure and/or flow rate.
[Tips]
Regarding the minimum required flow rate, refer to “8.1 Specifications”.
When any abnormality is found, press the [STOP] key to stop the
product operation, and then turn OFF the breaker of the user’s power
supply.
