Chapter 5 Display and Setting of Various Functions
HRSH Series 5.6 Key-lock
5-13
5.6 Key-lock
5.6.1 Key-lock
The keys can be locked to prevent the settings being changed by an
operator error. Operation can be started / stopped by operating the
“RUN/STOP” key even when the key-lock is being activated.
If you try to change the set value with the “▲” key or ”▼” key while the
key-lock function is activated, “ ” will be displayed for 1 second, and
it is not possible to change the set value. (Refer to the Fig. below.)
PV
SV
PV
SV
While the key-lock function is being activated, no other setting is
available.
Release the key-lock setting for other settings.
