No.DIG-31900-OM002
59
Normal end
＊See fig. 44 for details
Balance current
being evaluated
After balance
Current adjustment
Balance current readjustment
K
Fig. 44-3
Mode button
（ ）
≧1s
Set button
＋
（ ）
≧1s
Set button
＋
（ ）
≧1s
Set button
＋
（ ）
≧1s
Readjustment
necessary
Normal end
L
Fig. 44-4
Mode button
（ ）
≧1s
Set button
＋
（ ）
≧1s
Set button
＋
（ ）
≧1s
Set button
＋
（ ）
≧1s
Error
