■Parameter Setting Default Value List
Table 13 shows the parameter default values set at shipment. Please refer the table below when
you repeat setting change and want to default the setting.
Parameter
Set items
Parameter item
Details
Setting
assigned
Status
Set value 1
Set value 2
(000) Actuator type
-
Not
changeable
-
-
(200) Operating direction
-
-
dir
-
(300) Split range setting
-
oFF
-
0.0
100.0
(400) Zero-span setting
-
oFF
-
0.0
100.0
(500) Forced fully close/
open
-
on
-
0.5
99.5
(600)Dead band
-
-
-
0.0
-
(700) Valve open degree
characteristic
-
-
Lin
-
-
(User set value)
0.0
1.0
4.0
9.0
16.0
25.0
36.0
49.0
64.0
81.0
100.0
(800) PID constant setting
Proportional gain
(P constant)
-
-
0.150
Integral time
(I constant)
-
-
0.100
Differential time
(D constant)
-
-
0.250
Easy adjustment
(All constant)
-
-
0
(900) Alarm 1 setting
OFF
(A00) Alarm 2 setting
OFF
(b00) Analogue output
setting
-
inC
Table13
