C
HAPTER
4
| Configuring the Switch
MLD Snooping
– 145 –
This attribute will take effect only if MLD snooping proxy reporting is
enabled (see page 140).
â—† URI - The Unsolicited Report Interval specifies how often the upstream
interface should transmit unsolicited MLD reports when report
suppression/proxy reporting is enabled. (Range: 0-31744 seconds,
Default: 1 second)
WEB INTERFACE
To configure VLAN settings for MLD snooping and query:
1. Click Configuration, IPMC, MLD Snooping, VLAN Configuration.
2. Adjust the MLD settings as required.
3. Click Save.
Figure 55: Configuring VLAN Settings for MLD Snooping and Query
CONFIGURING MLD
FILTERING
Use the MLD Snooping Port Group Filtering Configuration page to filter
specific multicast traffic. In certain switch applications, the administrator
may want to control the multicast services that are available to end users;
for example, an IP/TV service based on a specific subscription plan. The
MLD filtering feature fulfills this requirement by denying access to specified
multicast services on a switch port.
PATH
Configuration, IPMC, MLD Snooping, Port Group Filtering
PARAMETERS
These parameters are displayed:
◆ Port – Port identifier.
◆ Filtering Groups – Multicast groups that are denied on a port. When
filter groups are defined, MLD listener reports received on a port are
checked against the these groups. If a requested multicast group is
denied, the MLD report is dropped.
WEB INTERFACE
To configure MLD Snooping Port Group Filtering:
1. Click Configuration, IPMC, MLD Snooping, Port Group Filtering.
