C
HAPTER
5
| Monitoring the Switch
Displaying Information on LACP
– 231 –
WEB INTERFACE
To display LACP status for local ports this switch, click Monitor, LACP, Port
Status.
Figure 108: LACP Port Status
DISPLAYING LACP
PORT STATISTICS
Use the LACP Port Statistics page to display statistics on LACP control
packets crossing on each port.
PATH
Monitor, LACP, Port Statistics
PARAMETERS
These parameters are displayed:
◆ Port – Port Identifier.
◆ LACP Transmitted – The number of LACP frames sent from each port.
◆ LACP Received – The number of LACP frames received at each port.
◆ Discarded – The number of unknown or illegal LACP frames that have
been discarded at each port.
WEB INTERFACE
To display LACP statistics for local ports this switch, click Monitor, LACP,
Port Statistics.
Figure 109: LACP Port Statistics
