GW2145 - GW1160 - GW4060 - GW4190
fig. 51 – GW4190 series: the detergent intake hose connections are accessible in the side cabinet. P3 is always optional.
INSTALLATION ON STAND
If the device is installed on a stand (e.g. for GW1160, GW4060: Smeg product “B6040”) with having height (base
height) "HB", all the measurements of height above the supporting surface provided in this document must be
increased by the said height “HB”.
HMi = Hi + HB
Where:
Hi = normal height stated in the document
HB = height of appliance stand
HMi = height recalculated for appliance installed on stand
fig. 52 – Smeg B6040 Stand.
