Snap‐onEEWB330AHandspinWheelBalancer
5.9Weightapplication

Thefollowingweighttypesandapplicationmethodsare
available:‐clip‐onweights:Alwaysapplybyhand(Fig.5‐
17).‐stick‐onweights:Mustbeappliedbyhand(Fig.5‐
18),orusingthegaugehead,fortheAlu2P,Alu3Por
easyweightmode.

Note:Handappliedweightsmustbeappliedexactly
perpendiculartotheshaft(12o’clockposition).After
spinningthewheellookattherotationindicatorsforthe
leftplaneofthewheel(1,Fig.5‐19):Asthecorrect
wheelanglepositiongetscloserafurtherindicatorlights
up.WhenalltheindicatorsareON(2,Fig.5‐20),the
WAPindicatorwillalsolightup(3‐Figura5‐20). Note:
Whenthecorrectangleisreachedalltherotation
indicatorsshouldbeON.Ifthewheelhasbeenpushed
toofar,onlytheindicatorsoftheotherhalfwillcome
ON(Figure5‐21).Ifthishappens,thewheelmustbe
delicatelyturnedintheoppositedirectionuntiltheWAP
positionisreached.Theweighttobeappliedinthat
planeisshownonthedisplay.

Attachingaclip‐onweight.

RefertoFigure5‐17.Clip‐onweightsmustalwaysbe
appliedinthe12o’clockposition.Thelipshouldreston
therimedge.Usetheweightplierstopositionit.In
STATICmodeonlythelefthanddisplayisused.

Attachingastick‐onweight.

ALUorSTATICweightmodesonly:RefertoFigure5‐18.
Applytheweightontheriminthe12o’clockposition,
alwaysbyhand.

Note:WithSTATICweightmodes,alwaysapplythe
weightattherimcentreline.Ifnotpossible,splitthe
weightsevenlyandapplyonanothersurfaceoftherim
(symmetricaltotherimcentreline).
