Snap‐onEEWH330AHandspinWheelBalancer
PRE‐INSTALLATIONCONSIDERATIONS
1.7DIMENSIONSOFTHEMACHINE



Figure4‐ActualFootprintDimensions.

1.8REQUIREDINSTALLATIONAREA

Make sure that from the operating position the
user can see all of the machine and the
surroundingarea.


The operator should prevent non authorized
persons and/or objects from entering the area
whichmaycre‐atepotentialhazards.

The machine should be installed on a stable level
floor.Donotinstallthemachineonaunevenfloor.

If the balancer is to be installed on a raised floor,
thefloormusthaveacapacityofatleast110lbsper
sqft.(5000N/m²‐500kg/m²).

It is not required to secure the machine to the
floor.

Installthemachineinadry,coveredarea.

The installation of themachinerequires a working
area of at least62” x50”(1574x 1270 mm)
(Figure5).

NOTE:Donotinstallthebalance
rbelowgradelevel
orinapit.





Figure5‐RecommendedWorkArea

1.9INSTALLATIONINSTRUCTIONS

CAUTION!CAREFULLYREMOVETHEBALANCERFROM
THEPALLET.
Removethehardwarethatsecuresthemachinetothe
palletandslidethebalancerontothefloorwhereitisto
beinstalled.
THEUNITISHEAVYANDTHEWEIGHTISNOTEVENLY
DISTRIBUTED.
DONOTLIFTTHEBALANCERBYTHESHAFT.
DROPPINGTHEUNITMAYCAUSEPERSONALINJURY
OREQUIPMENTDAMAGE.

2.0BALANCERINSTALLATION
MountingtheShaftAdapter
IMPORTANT!CHECKTHATTHESURFACESARE
PERFECTLYCLEANANDNOTDAMAGED.ANINCORRECT
MOUNTINGMAYRESULTINSIGNIFICANTIMBALANCE.
A. Mountthethreadedshaftontothearborofthe
bal‐ancer.Tightenfirmlyusingsuppliedrod.
(Figure6).

 




