5.5.1SelectingtheAlutypes
Imagesshowsthecorrectedweightapplicationpositions
foradhesiveweightsandclip‐onweights.Note:The
Alu1PmodeisincludedintheEasyalufunction,butmust
berecalledafterthegaugehavebeenpositionedonthe
rim.
*Selectthemenukey(Fig.5‐12)torecalltherequired
ALUPweightpositions.
Fig.5‐13Givenweightpositionnormal.Normalweight
andclip‐onweightpositionsontherimflange‐this
modeispresentedimmediatelybytheEasyalufunction.

Alu1Adhesiveweightsappliedsymmetricallytotherim
flangeswithNOMINALweightpositioning.Functionnot
includedinEasyalumode.

Alu1PAdhesiveweightsappliedsymmetricallytothe
rimflanges;thecompensationplanesfortheadhesive
weightsarereadpreciselyusingtheinternaland
externalgaugearm.

Alu2Adhesiveweights‐Adhesiveweightonrimflange,
adhesiveweighthiddeninrimdiscwithNOMINAL
positioning.FunctionnotincludedinEasyalumode.

Alu2PAdhesiveweights‐Adhesiveweightonrim
flange,adhesiveweighthiddeninrimdisc;the
compensationplanesfortheadhesiveweightsareread
preciselyusinginternalcalibration.

Alu3Clip‐onweightonleftrimflange,adhesiveweight
hiddeninrimdisc.FunctionnotincludedinEasyalu
mode.WeightpositioningisNOMINAL.

Alu3PClip‐onweightonleftrimflange,adhesiveweight
hiddeninrimdisc;thecompensationplanesforthe
adhesiveweightisreadpreciselyusinginternal
calibration.

Alu4Balanceclipfittedonleftrimflange,adhesive
weightattachedtorightbeadseat
