Snap‐onEEWB330AHandspinWheelBalancer
5.9.1Alu2PandAlu3P(HWM)weightmodes:

RefertoFigure5.22.Thegaugearmmustbeusedto
applythestick‐onweight(s).Indexthewheeltothe
exactpositionforcorrectionintherightcorrection
plane.Oncethecorrectweightapplicationpositionis
reached,onlythecentralLEDison(1,Figure5.23).Press
thepedalofthemainshaftlocktoholdthewheelinthis
position.DecidetouseSplitWeightMode«SWM»now

(5.10).Cleanthefittingpositionbeforeattachingthe
adhesiveweights.Insertatthecentreofthegaugearm
anadhesiveweightthatcomplieswiththeimbalance
measuredandremovetheprotectivetapefromthe
adhesivestrip(a,Figure5‐24).
Note:Whilemovingthearm,abeepindicatesthatthe
correctapplicationpositionhasbeenreached.Applythe
weighttothecorrectpointontherim.

Applytheweighttothecorrectpointontherim.Rotate
thewheeltothenextWAPposition(2,Fig.5.23),put
thestick‐onweightonthegaugearmandapplythe
weightattheleftplanereferencepoint.
AfterapplyingthebalanceweightsperformaTestRun.

5.9.2CheckspinItisgoodpracticetoperformacheck
spinafterapplyingtheweights.Spinthewheel.Having
finishedtheTestRun,ifthewheelisbalancedcorrectly,
boththenumericalindicatorsshouldindicate000.To
checkhowmuchimbalanceisleft:SelecttheFINEkey
(Fig.5‐25). Note:Theoperatorshoulddecideifapplying
thestatedweight.

5.9.3Resultsrecalculation.Afterspinningawheelitis
possibletoenternewrimdataorselectanotherweight
mode.Theresultsarerecalculatedautomatically,if
possible.Selectinganotherweightmode‐Between
NORMAL,ALUandSTATIC:Noadditionalstepsrequired.
Tohavearecalculationdone:Selecttherequiredweight
mode.Checkand/oreditrimorplanedatawhen
necessary.RotatethewheeltotheleftplaneWAP
positionandapplytheweight.Rotatethewheeltothe
rightplaneWAPpositionw
eightandapplytheweight.
Performacheckspin
check.
