Snap‐onEEWB330AHandspinWheelBalancer


5.12.3WeightUnitToggleMode
Settingthebasicweightunit:grams.Selectthismodeto
changetheunitofmeasureoftheweightbeforeorafter
carryingoutabalancingoperation.Selectthe“MODE”key
untiltheweightunitsindicatorflashes.The“oz”
indicatorwillstartflashing.Thedisplaynowequals
Figure5‐43.SelectReturn.Theweightsettingstatus
nowcalculatesweightsusingadifferentunitofmeasure
(fromgramstoouncesorfromouncestograms).The
programreturnstothemainmenu.

5.12.4DimensionUnitToggleMode
Settingthebasicunitofmeasurefordiameterand
width:inches.Selectthismodetochangetheunitof
measureofthediameterandwidthbeforeorafter
carryingoutabalancingoperation.Selectthe“MODE”
key untilthedime
nsionalunitsindicatorblinks.The“mm”
indicatorwillstartflashing.Thedisplayshouldnow
appearas
showninFigure5‐44.

Note:MakesurethatallthepresetPAXunitshavebeen
removed.Theoperatorcannowselecttheunitsinsteps
of1mmifthemmmodehasbeenselected.Select
return.Thestateofthediameterandwidthdimension
unitswilltoggle(inchtomm,ormmtoinch).Offsetis
alwaysmeasuredandshowninmillimeters.

Theprogramreturnstothemainmenu.
