Snap-On EEWB330A User Manual

Snap‐onEEWH330AHandspinWheelBalancer
1.3EEWB330ASPECIFICATIONS

Computerizeddigitalwheelbalancerforcar,light
truckwheels.

WeightImbalanceAccuracy.10oz/2grams
WeightPlacementResolution±.7degrees
WeightImbalanceResolution:
RoundoffMode.25oz/5grams
Non‐RoundoffMode.05oz/1gram
Max.ShaftWeightCapacity120lbs/54kg
Max.TireDiameter42"/1067mm

RimWidthCapacity3
"‐20"/76mm‐508mm

Rim DiameterCapacity8"‐30"/203mm‐762mm
BalancingCycleTi
me.6 to 8secondsorless
Shaft Speedatcalculation<100RPM
Electrical1151ph,60Hz,2A
RequiredWorkArea62"wx
50"d1524x1270mm
ShippingW
eight,unit/pallet/carton210lbs/99kg
Shippi
ngDimensions48”h40”w28”d
MachineDimensions40”h38”w21”d
ActualWeightwithAccess
ories174
lbs/79kg
OperatingTemperatureRange32‐122F/0‐50C











1.4FEATURES

ACCURACY
•Weightplacementaccuracyis±.7°
•Weightimbalanceaccuracyto2grams.
•Selftestcheckwitheverypowerupcycle.
•Fastoperatorcalibration.
•Pre‐programmedErrorCodesindicateprocedural
errorsorsafetyconcerns.

SPEEDandDURABILITY
•Automaticdistanceanddiameterentry.Simplytouch
theSAPEarmtothewheel,thedistanceanddiameter
parameterisautomaticallyentered.
•Quickclampspeednutreduceswheelmountingtime.
•Capturedbackspringeliminateshavingtohandlethe
backingspring.
•Quickcycletime.
•Automaticrecalculationifweightpositionsare
changed.Noneedforre‐spinningthewheel.
•Common40mmdiametermountingshaft.
•Weightpocketstoragetray.
•Easy‐to‐ReadDatadisplay.
•Easyweighttrayaccess.

SOFTWAREVERSATILITY
•BothdualweightDynamicandsingleweightStatic
capability.
•MatchBalanceprogramforreducingweightrequired.
•Built‐inspincounterformonitoringbalancer
productivity.
•ServicecodeaccesstoallBalancerelectronic
functionsforfast,easydiagnosis.
•Operatorselectableroundoffmode.
•5AluminumModes
•Alu‐Smode
•Ounce/Gramtogglefromfrontpanel
•Multipleoperatorfeatureallowsseveraloperatorsto
recallwheelparameters.







