Snap-On Ultra - Calibration Utilities; System Configuration

30
CALIBRATION
CALIBRATION UTILITIES
The Calibration Utilities are special utilities
designed to calibrate different parts of the
alignment system. It also includes a utility
used to back up the calibration data and to aid
a technician in the proper troubleshooting of
the V3D system
.
ISO
Utility used for performing ISO calibration. A special xture is required to perform this
procedure. The procedures are included with the xture. This should only be done by
a qualied technician.
SYSTEM CONFIGURATION
Utilities used to congure the systems camera conguration.
TID
Utilities used for performing Target Identication for the different types of clamps avail-
able to the end-user including Standard Clamps; AC200, AC400, AC900 and others.
CAMERA VIEW
Live camera view. This utility is very useful for determining proper camera operation.
RELATIVE CAMERA POSITION (RCP)
Process used to identify the camera’s distance from one another.
RIDE HEIGHT TARGET CALIBRATION
Utility used to calibrate the “Ride Height Target” if available.
CALIBRATION UTILITIES
Utility used for backing up calibration data.
