Lit. No. 30118, Rev. 00 June 15, 2020
16
HYDRAULIC SYSTEM
CARTRIDGE VALVES
The RDV™ V-plow hydraulic system performs ten
blade movement functions.
All functions require the vehicle ignition (key) switch
to be in the "RUN" or "ACCESSORY" position and
the power to be activated on the snowplow cab
control.
Blade Movement
Solenoid
ATTACH DETACH
Scrape
Maxx™
FEATURE
(OPT)
Motor M ON ON ON ON ON ON ON ON ON ON ON ON
SV08-2211 S1 ON ON ON
SV08-47D
S2C1 ON ON
S2C2 ON
SV10-43 S3 ON ON
SV08-2211 S4 ON ON ON
SV08-47C
S5C1 ON ON ON
S5C2 ON ON ON
SV08-47C
S6C1 ON ON
S6C2 ON ON
VEE SCOOP EXTEND
LEFT
ANGLE
LEFT
ANGLE
RIGHT
RAISE LOWER
RIGHT
RETRACT
RIGHT
EXTEND
LEFT
RETRACT
Nine of the ten hydraulic functions require
energizing the electric motor and opening solenoid
cartridge valves. The LOWER function does not
energize the motor but requires the opening of
one cartridge valve.
Power from the vehicle battery is supplied to the
solenoid coils and the motor relay via the plow
module. The solenoid cartridge valves operate in
various combinations, directed by the cab control,
to send hydraulic fl uid to the snowplow lift and
angle rams or back to the reservoir. (Power is
supplied to the plow module via the battery cable
and motor relay connection.)
