TROUBLESHOOTING
INDIVIDUAL SOLENOID COIL TEST
1. Remove both wires from coil terminals.
2. Attach an ohmmeter across the coil terminals.
3. A reading that is not approximately 7 ohm
indicates coil is damaged and must be
replaced.
4. Attach an ohmmeter to one coil terminal and to
the steel washer at the end of the coil.
5. A reading that is not "open" indicates that
the coil has internal shorts and needs to be
replaced.
6. If both readings are approximately 7 ohm
across terminals and "open" between terminal
and washer, then the coil is good.
NOTE: A good coil will draw approximately 1.5A.
