socomec MASTERYS IP Plus User Manual

ENGLISH
IOMMASIPXX09-GB 04 17
10-40 kVA
MASTERYS IP+
3
UNPACKING AND INSTALLATION
OF THE UNIT
TO LOAD
cable section
ø 6÷35 mm
2
MAINS
cable section
ø 6÷35 mm
2
AUXILIARY
MAINS
cable section
ø 6÷35 mm
2
EXT. BATTERY
+B2 -B2 -B1 +B1
OUTPUT
MAINS
SUPPLY
IN
TRANSFORMER
L11A L11 N11A N11 L14 N4 N3L13 L12 N2L1 L2 L3 N
AUXILIARY
MAINS
OUT
TRANSFORMER
3/1
MAINS AND AUXILIARY MAINS ARE CONNECTED SEPARETELY.
Output transformer
AUXILIARY
MAINS
cable section
ø 16÷50 mm
2
TO
LOAD
MAINS
cable section
ø 6÷35 mm
2
Cables
Cables
provided
provided
Cables
Cables
provided
provided
N3
EXT. BATTERY
+B2 -B2 -B1 +B1
OUTPUT
MAINS
SUPPLY
IN
TRANSFORMER
OUT
TRANSFORMER
L11 L21 L31 N1 L14 L24 L34 N4 L13 L23 L33 L12 L22 L32 N2L1 L2 L3
TA1
TA2
AUXILIARY
MAINS
3/3
UPS IN NEUTRAL VERSION WITHOUT NEUTRAL ON THE NETWORK
output transformer
Cables
Cables
provided
provided
Do not combine the main network and the auxiliary network
