8
under adverse conditions the device must be mounted in an additional casing that
meets the requirements of the required protection class.
The ambient temperature must be between –20 °C and +40 °C.
To connect the plug-in power supply a 230 V power socket must be within reach of
the connection cable.
For the GPRS version, the GSM signal of the respective mobile communications pro-
vider must be adequately strong. The GSM must be installed in a suitable location.
4�4 Device installation
Wall
Attach the two grey PVC parts to the back of the device using the enclosed screws. The
device can now be simply installed at the selected location.
Top-hat rail
Attach the two grey metal parts to the back of the device using the enclosed screws. The
device can now be simply hooked into a 35mm top-hat rail.
5 Installation of the MaxComm
network
5�1 Connection options
Up to 75 devices with a MaxComm interface can be connected to your MaxWeb xp data
logger.
Device Purpose
SolarMax inverters All SolarMax inverters from the E and C series
MaxMeteo Module for connecting a temperature and irradiance sensor
MaxCount Module for connecting pulse counters with S0 interface (utility
companies)
MaxConnect plus Generator connection box with string current monitoring
MaxDisplay 1.0 / 2.0 LCD or LED large displays with MaxComm interface / Large
displays with a MaxComm interface are offered by several display
manufacturers
