Below table shows some conventional and reasonable loads for you reference.
Type
Power
Start
Rated
Common
equipment
Example
Resistive
load
Inductive
load
Capacitive
load
X 1
X 2
X 1
X 1.5
X 3~5 X 2
Start
Rated
100VA
(W)
100VA
(W)
80VA
(W)
60VA
(W)
450-750VA
(W)
300VA
(W)
Equipment
Fluorescent lamp
Fluorescent lamp
40W
Fan
Fridge Fridge
150W
Incandescent
lamp
TV Incandescent
lamp
100W
You can additionally earth the inverter enclosure of a second earthing or
equipotential bonding is required locally. This prevents touch current if the
original protective conductor fails.
Cable size: 12AWG.
Connection step:
1. Strip the earthing cable insulation.
2. Insert the stripped cable into the ring terminal.
3. Clamp the end of the ring terminal.
4. Unscrew the screw of the earthing connector.
5. Suit the ring terminal on the earthing connector .Suit the gasket on the
earthing connector.
6. Screw the screw of the earthing connector.
Earth connection.●
