SolaX Power SK-TL3000 - The Main Steps to Connect The X-Hybrid System

PV module voltage is very high which belongs to dangerous voltage
range, please comply with electric safety rules when connecting.
WARNING!
When the photovoltaic array is exposed to light, it supplies a D.C
voltage to the PCE.
WARNING!
When there is something wrong with the modules arrays. Modules
can be connected with inverter only after eliminating these problems.
WARNING!
Ÿ PV string connection
The following requirements of PV modules need to be applied for
each input area;
• Same type • Same quantity • Identical alignment • Identical tilt
NOTE!
6.6 Connections of The X-hybrid System
6.6.1 The Main Steps to Connect The X-Hybrid System
-PV string connection
-AC output connection
-Battery connection (for SK-SU series)
Battery power connection
Battery communication connection
Battery thermal sensor connection
-Current sensor connection
-EPS connection (for E version)
-Earth connection
-Wifi connection
X-hybrid series inverters can be connected in series into 2-strings PV modules
for 3.7KW and 5KW, and 1-string PV module for 3KW.
Please select PV modules with excellent function and reliable quality.
Open-circuit voltage of module arrays connected in series should be <Max. DC
input voltage; Operating voltage should be conformed to MPPT voltage range.
Table 3 Max. DC Voltage Limitation
Model SK-TL(SU)3000 SK-TL(SU)5000
Max. DC Voltage(V)
MPPT voltage range(V)
550
125-530
SK-TL(SU)3700
