PE Connection and Leakage Current
• The end-use application shall monitoring of the protective conductor by residual
current operated protective device (RCD) with rated fault current Ifn≤240mA
which automatically disconnects the device in case of a fault.
• DC differential currents are created (caused by insulation resistance and through
capacities of the PV generator). In order to prevent unwanted triggering during
operation, the rated residual current of the RCD has to be min 240mA.
The device is intended to connect to a PV generator with a capacitance limit of
approx 700nf.
High leakage current!
Earth connection essential before connecting supply.
WARNING!
• Incorrect grounding can cause physical injury, death or equipment malfunction
and increase electromagnetic.
• Make sure that grounding conductor is adequately sized as required by safety
regulations.
• Do not connect the ground terminals of the unit in series in case of a multiple
installation. This product can cause current with a d.c component, Where a residual
current operated protective (RCD) or monitoring (RCM) device is used for protection
in case of direct or indirect contact, only an RCD or RCM of type B is allowed
on the supply side of this product.
• For Australia and New Zealand:
The installation of inverter must fulfill Australia national Wiring rules AS/NZS3000,
AS/NZS4777.1 and AS/NZS5033.
Do not work on the inverter when the device is running.
WARNING!
• Never touch either the positive or negative pole of PV or battery connecting
device. And never ever touch both at the same time.
Risk of electric shock!
WARNING!
• Use only attachments recommended or sold by SolaX.
• Make sure that existing wiring is in good condition and that wire is not undersized.
Do not operate the X-Hybrid Series inverter with damaged or substandard wiring.
• Do not disassemble the X-Hybrid Series inverter. It contains no user-serviceable
parts. See Warranty for instructions on obtaining service. Attempting to service
the X-Hybrid Series inverter yourself may result in a risk of electric shock or fire
and will void your warranty.
• Keep away from flammable, explosive materials to avoid fire disaster.
• The installation place should be away from humid or corrosive substance.
• Authorized service personnel must use insulated tools when installing or working
with this equipment.
• PV modules shall have an IEC 61730 class A rating.
