● LCD Digital Display
The main interface is the default interface, and the inverter will automatically jump
to this interface when the system starts up successfully or be not operated for
a period of time.
The information of the interface is as below. The “Power” means the timely
output power; “Today” means the power generated within the day. “Battery”
means the left percentage of battery energy.
“Normal”show the status of the inverter.
7.3 LCD Operation
Power 0W
Today 0.0KWh
Battery %
Normal
● Menu Interface
The main interface is a transfer interface for user to get into the other interface
to finish the setting or to get the information.
- User can get into this interface by pressing “OK” button when the LCD displays
the main interface.
- User can select interface by moving the cursor with the function button, and
press “OK” to confirm.
Status
History
Settings
Menu
● Status
The status function contains four aspects of the inverter, grid , solar, battery
and EPS.
Press up and down to select and press “OK” to confirm the selection, press “ESC”
to return to the Menu.
Grid
Solar
Battery
Status
A) Grid
This status shows the real time grid condition such as voltage, current, output
power and the local consumed power . Pout measures the output of the inverter,
Pgrid measures the export to or import from the grid. Positive value means the
energy feed into grid. Negative value means the energy used from grid.
Press up and down button to review the parameter. Press “ESC” to return to
Status .
U 000.0V
I 00.0A
P 00.0W
Grid
To Next Page
