F) Power Factor ( For specific country if required by the local grid.)
There are 5 modes for selecting: Off , Under-Excited, Over-Excited, Curve, Q( u ).
All parameters are shown below.
Mode Comment
Off
Under-Excited PF value
Over-Excited PF value
Curve
Upper limit
Lower limit
Power Upper
Power Lower
PFLockInPoint ( CEI 0-21 only)
PFLockOutPoint ( CEI 0-21 only)
Q( u )
QuVupRate
QuVlowRate
-
( EN50438_NL / EN50438_DK / E8001 only)
( EN50438_NL / EN50438_DK / E8001 only)
Operation Method
43
D) New Password
User can set the new password here. We need to increase or decreased the
word by pressing up or down button. Press “OK” to confirm and alternate to the
next word. After all the words are confirmed. Press “OK” to reset the password.
1 2 3 4
New Password
E) PV Connection
This function can set the mode of PV input. There are two modes for choice:
Comm and Multi. The “Comm” mode mean single MPP tracking ,2 MPPT
working together; “Multi” means multi-MPP tracking, 2 MPPT work independently.
Press up or down button to select and press “OK” to confirm.
PV Connection
Multi
PV Connection
To Next Page
