17
Unpacking and Inspection
• Be careful when dealing with all package materials which may be reused for
storage and relocation of the EV-Charger in the future.
• Upon opening the package, check whether the appearance of the EV-Charger is
damaged or lack of accessories. If any damage is found or any parts are missing,
contact your dealer immediately.
5.2 Scope of Delivery
EV-Charger × 1
Expansion tube × 3 or 5
(3 for Socket Type,
5 for Plug Type)
Ferrule × 3 or 5
(3 for single-phase,
5 for three-phase)
CT (for single-phase) or
CT (for three-phase) × 1
Documents
RJ45 connector
(black) × 1 *
Inverter connector
(white) × 1 *
Self-tapping screw × 3
or 5 (3 for Socket Type,
5 for Plug Type)
Washer × 3 or 5
(3 for Socket Type,
5 for Plug Type)
RFID card × 2
Cable hook × 1
(Only for Plug Type)
* The black RJ45 connector is for extension connection of CT or network, while the white
inverter connector is specially supplied for connecting inverter.
