50
Operation Method
• Plug & charge pattern
For Socket Type, the electronic lock will be locked when the EV-Charger starts
charging and unlocked automatically when the charging stops.
For Plug Type, there is no electronic lock.
• Card-swiping pattern and APP activation pattern
For Socket Type, the electronic lock will be locked when the EV-Charger starts
charging after swiping the card or touch correponding charging mode area on
the control page of the App. If the charging process is stopped by the user (either
by swiping card or touch Stop on the App), the electronic lock will be unlocked
automatically. If the charging process is completed (i.e. the EV is fully charged),
the electronic lock should be unlocked by swiping the card.
For Plug Type, there is no electronic lock.
OCPP scene
While in OCPP scene only card-swiping pattern is available and should be in accordance
with the OCPP server. For Socket Type, the electronic lock will be locked when the EV-
Charger starts charging after swiping the card, and the charging process will end after
swiping the card for the first time and the electronic lock will be unlocked after swiping for
the second time.
NOTICE!
• In emergency cases, please stop the EV-Charger by pressing the EMERGENCY STOP
button.
9.3 Application Scene Setting
The default Application scene is Home. If the user wants to use the OCPP scene, select
on the setting page following the path: Charger setting > Application scene > OCPP.
Cancel OK
Home
OCPP
Figure 9-1 Select OCPP as Application scene
In OCPP scene, the EV-Charger can be connected with the OCPP server. Before choosing
this scene, please ensure that the EV-Charger has met the following prerequisites:
• The EV-Charger has joined the network that can access the Internet through
network connection.
