II
About This Manual
Scope of Validity
This manual is an integral part of X1/X3-EVC Series EV-Charger.
It describes the installation, electrical connection, commissioning,
maintenance and troubleshooting of the product. Please read it carefully
before operating.
X1-EVC-7.2K(SXC) X1-EVC-7.2K(PXC)
X3-EVC-11K(SXC) X3-EVC-11K(PXC)
X3-EVC-22K(SXC) X3-EVC-22K(PXC)
X1-EVC-7.2K(SLC) X1-EVC-7.2K(PLC)
X3-EVC-11K(SLC) X3-EVC-11K(PLC)
X3-EVC-22K(SLC) X3-EVC-22K(PLC)
X1-EVC-7.2K(SXC)-P X1-EVC-7.2K(PXC)-P
X3-EVC-11K(SXC)-P X3-EVC-11K(PXC)-P
X3-EVC-22K(SXC)-P X3-EVC-22K(PXC)-P
Note:
"X1" means single-phase, "X3" means three-phase.
"EVC" means "EV-Charger".
"7.2K" means that the nominal output power is 7.2 kW, so does for "11K"
and "22K".
"S" means Socket Type, only socket outlet, “P” means Plug Type (also
called Connector Type), with charging cable and connector.
"X" means without LCD screen, "L" means with LCD screen.
"C" means commercial edition.
"-P" means with PEN protection function.
Target Group
The installation, maintenance and grid-related setting can only be
performed by qualified personnel who
• Are licensed and/or satisfy state and local jurisdiction regulations.
• Have good knowledge of this manual and other related documents.
