37
Mechanical Installation
Step 3: Attach the wall bracket to the wall again, and correctly insert and tighten
expansion screw (Part G) (× 4 pcs) to secure the wall bracket (Tightening torque:
14-16 N·m).
14-16 N·m
Figure 6-11 Tightening expansion screw
NOTICE!
• Please make sure that it is level via the cylindrical plastic bubble spirit level on the wall
bracket.
