39
Mechanical Installation
NOTICE!
• At least two persons are required to lift the battery module.
• The battery module shall be located against the wall bracket.
Step 6: Draw a circle along the inner ring, with one on each side.
Then gently carry the battery module down to the ground.
Figure 6-14 Drawing circles
NOTICE!
• It needs a second person to hold the battery module to prevent it from falling from
the wall bracket when installation.
