Solcon MPS 3000 User Manual

MPS3000 TERMINALS
Page 11 of 67
T1 ................................................... 66+67, 68
T2 ................................................... 69+70, 71
T3 ................................................... 72+73, 74
T4 ................................................... 75+76, 77
T5 ................................................... 100+101, 102
T6 ................................................... 103+104, 105
T7 ................................................... 106+107, 108 (Leave 106 open for thermistor, see note 2 above)
T8 ................................................... 109+110, 111 (Leave 109 open for thermistor, see note 2 above)
T9 ................................................... 112+113, 114 (Leave 112 open for thermistor, see note 2 above)
T10 .................................................. 115+116, 117 (Leave 115 open for thermistor, see note 2 above)
Note - If Temp sensors are not used, leave all relevant terminals open. Disable all the relevant Trip and Alarms.
Twisted and Shielded cables must be used for all temperature inputs. Shield should be connected to Chassis
Ground externally, near the MPS3000.
Analog Outputs
The MPS3000 incorporates four programmable analog outputs. Outputs type can be programmed to 4..20 mA
or 0..20 mA. Load resistance should be less than 400Ω. The four outputs share one common point. 0..1 mA
type is also available. Each output can be configured to represent one of twenty different parameters. Outputs
are updated every 100mS. Range of parameter for each output is fully programmable.
Analog Out 1 .................................. 121
Analog Out 2 .................................. 122
Analog Out 3 .................................. 123
Analog Out 4 .................................. 124
Analog Out Common ..............….......... 125
Note: The analog outputs electronics is isolated as one group together with the Analog inputs (and with the
Temperature input) circuits. Please note that only one common connection (Ground) have to be used for the
analog inputs and outputs. (The Temperature input wires are normally individually isolated, so they have no
common connection).
Twisted and Shielded cable must be used for all analog outputs. Shield should be connected to Chassis
Ground externally, near the MPS3000.
Analog Inputs
The MPS3000 incorporates four programmable analog Inputs. Each input can be individually programmed for
4..20 mA or 0..20 mA types. The four inputs share one common point. 0..1 model is available. A fault protection
is assigned for each analog input. Level and time delay is adjustable for each input. Scan cycle time: 100mS.
Analog In 1 ................ ..................... 126
Analog In 2 ...................................... 127
Analog In 3 ...................................... 128
Analog In 4 ...................................... 129
Analog In Common ............................... 130
Note: The analog inputs electronics is isolated as one group together with the Analog outputs (and with the
Temperature input) circuits. Please note that only one common connection (Ground) have to be used for the
analog inputs and outputs. (The Temperature input wires are normally individually isolated, so they have no
common connection).
Twisted and Shielded cable must be used for all analog inputs. Shield should be connected to Chassis Ground
externally, near the MPS3000.
