FRONT PANEL SETTINGS
Startup
On startup the following occurs: ON and Stopped LED's are turned on
The LCD will display:
System Parameter
*** Settings ***
In order to review above page settings, press Select FWD. key.
Messages are displayed on the LCD in two lines.
* Upper line describes the parameter's name.
* Lower line shows its value.
When Authorized key terminals are open, it is possible to view parameters but not to change or store them.
An attempt to change a value by
▲
,
▼
or to store will result in "Unauthorized Access" message.
To change settings, when Authorized key is closed, press
▲
or
▼
keys and save the new value by pressing
Store key. Once data was properly stored in the non-volatile memory the LCD displays the 2 Sec. flash
message:
Data Saved OK
Notes:
1. A new parameter setting becomes effective only after storing it in the non-volatile memory.
Setting a parameter, without storing, and moving to another parameter, will return the
parameter to its previously stored value.
2. Any "set page" parameters can be viewed, altered and stored at any time. However, it is not
recommended to change and store important parameters while the motor is starting or running.
3. Any stored parameter is kept indefinitely in the non-volatile memory.
Reset to Factory Default Values:
Press Set Page key and ▲key simultaneously, the LCD will display:
Test/Maintenance
*** Options ***
Press Select FWD. key three times, the LCD will display:
Store Now ?
Default Settings
Press Store and Set Page keys simultaneously, the LCD will display:
Data Saved OK
Note: Storing Default parameters erases all previously updated parameters
