TEST / MAINTENANCE OPTIONS
Page 61 of 67
TEST / MAINTENANCE OPTIONS
Push Set Page & ▼simultaneously to enter the test & Test & Service page.
Test/Maintenance
*** options ***
The test page is used for running the self-test, displaying program version, storing factory default
parameters into the non volatile memory, resetting and storing statistical data, setting of Real Time Clock
and for Fault Simulation. All this can only be done by a “key holder". Unauthorized personnel can only
view the test screens.
Display Description
Run Self Test ?
Push "Value-up"
Press ▲ key to initiate the built in test procedure.
Program Version
MPS-10-093092-Mb
Program version description.
Store Now ?
Default Settings
Stores All factory default parameters in the non-volatile memory.
Press Store and Set Page keys simultaneously, to store. "Data Saved Ok"
message will be displayed for about two seconds.
Clear Now ?
Statistical Data
Clears all statistical data. Press Reset and Data Page keys simultaneously,
to reset and store zero values in the non-volatile memory. "Data Saved
Ok" message will be displayed for about two seconds. The parameters are:
• Total run time
• Total # of starts
• Total # of trips
• Last start period
• Last start max I
• Thermal Capacity
• Last Trip
• Trip voltages and currents
• Active Energy (KWH)
• Reactive Energy (KVARH)
• "Data Saved Ok" message will be displayed for about two
seconds.
hh.mm mm.dd.yy
13:51 09/29/02
Real Time Clock date and time setting. Set and Store any of the five
parameters (pointed by cursor) normally, as for any other setting parameter.
Note that Store key forwards cursor to next parameter.
Warning
Default storing and resetting of statistical data should be done with care, since it is not possible to
retrieve the previous "set page" parameters or statistical data.
Setting Default parameters, delete all previous stored settings. !
Clearing Statistical Data resets all previous statistical data values. !
Note: For longer life, the Real Time Clock uses a backup capacitor and not backup battery. The Backup
capacitor retains data and keeps clock running for a few days. If the MPS3000 is not powered for longer
period, the clock has to be initialized. Initialization can be done manually as described above or through
serial link.
